Ceramic Structured Packing

Material: Alumina ceramic.

Apperance: Round.

MOQ: 1 cubic meter.

Color: Grey or white.

Size: Customized.

Type: Normal iron content and Low iron content.

Description：

Ceramic structured packing is also called ceramic corrugated packing. It has high surface area, low pressure drop per meter, low liquid loads. Widely used in vacuum columns, corrosive applications with theoretical stages and low pressure drop.

Material: Alumina ceramic.

Apperance: Round.

MOQ: 1 cubic meter.

Color: Grey or white.

Size: Customized.

Type: Normal iron content and Low iron content.

Description：

Ceramic structured packing is also called ceramic corrugated packing. It has high surface area, low pressure drop per meter, low liquid loads. Widely used in vacuum columns, corrosive applications with theoretical stages and low pressure drop.

Description：
Ceramic structured packing is a cylindrical unit composed of many packing unit bodies with the same geometric shape-corrugated sheets are parallel to each other and superimposed. Due to the unique structure of ceramics, it has good hydrophilic properties. The turbulence of the extremely thin liquid film and the inclined tortuous channels of the air flow can promote the air flow without blocking the air flow. So that the ceramic filler can match the metal filler. Its corrosion resistance and high temperature resistance are not comparable to metal fillers. It has large circulation, high separation efficiency, big surface area, low pressure drop, small liquid holding capacity etc advance.



Product Parameter

Chemical properties

Al2O3

≥23%

MgO

≤1.0%

SiO2

>72%

Fe2O3

≤0.5%

CaO

≤1%

Other

2%

Physical properties

Water absorption

≤0.5%

Specific gravity

2.5 g/cm3

Acid resistance

≥99.5%

Loss in bum

≤5%

Moh’s hardness

≥7 scale

Operating temperature

800 ℃ max

Crush strength

≥130Mpa



Spec.

Specific surface (m2/m3)

Bulk density     (kg/m3)

Void ratio

(%)

Obl. angle

Pressure drop
(mmHg/m)

Theo. Plate
(m-1)

Hydraulic diameter
(mm)

Liquid load
(m3/m2h)

Max. Factorm/s (Kg/m3)-1

125Y

125

320

90

45°

1.8

1.8

28

0.2-100

3

160Y

160

370

85

45°

2

2

15

0.2-100

2.8

250Y

250

420

80

45°

2

2.5

12

0.2-100

2.6

350Y

350

470

78

45°

2.5

2.8

10

0.2-100

2.5

400Y

400

500

75

45°

3

3

8

0.2-100

2

450Y

450

520

72

45°

4

4

7

0.2-100

1.8

550Y

550

620

74

45°

5.5

5-6

6

0.18-100

1.4

700Y

700

650

72

45°

6

7

5

0.15-100

1.3

100X

100

280

92

30°

1.5

1

30

0.2-100

3.5

125X

125

300

90

30°

1.8

1.5

28

0.2-100

3.2

160X

160

350

85

30°

2

1.8

15

0.2-100

3

250X

250

380

80

30°

2.5

2.3

12

0.2-100

2.8

350X

350

450

78

30°

3

2.5

10

0.2-100

2.6

400X

400

480

75

30°

4

2.8

8

0.2-100

2.2

450X

450

500

72

30°

4.5

3-4

7

0.2-100

2

470X

470

440

75

30°

5

5

7

0.2-100

1.8

550X

550

620

74

30°

5.5

5-6

6

0.18-100

1.4

700X

700

650

72

30°

6

7

5

0.15-100

1.3



Application

● Rectifying organic halide.

● Rectifying and absorbing some corrosive mixtures, which are definitely regulated in pressure drop and theoretic plate number.

● Applied in some towers that contain a large quantity of natural media used to absorb nitric acid and concentrated sulfuric acid, as well as for purifying the air in chemical plants.

● Operating in vacuum conditions at a bottom absolute pressure of 100pa.

● Used in heat ex changer and demisting, or as a catalyst carrier.

● Used in Chlorobenzene production.










Description：
Ceramic structured packing is a cylindrical unit composed of many packing unit bodies with the same geometric shape-corrugated sheets are parallel to each other and superimposed. Due to the unique structure of ceramics, it has good hydrophilic properties. The turbulence of the extremely thin liquid film and the inclined tortuous channels of the air flow can promote the air flow without blocking the air flow. So that the ceramic filler can match the metal filler. Its corrosion resistance and high temperature resistance are not comparable to metal fillers. It has large circulation, high separation efficiency, big surface area, low pressure drop, small liquid holding capacity etc advance.



Product Parameter

Chemical properties

Al2O3

≥23%

MgO

≤1.0%

SiO2

>72%

Fe2O3

≤0.5%

CaO

≤1%

Other

2%

Physical properties

Water absorption

≤0.5%

Specific gravity

2.5 g/cm3

Acid resistance

≥99.5%

Loss in bum

≤5%

Moh’s hardness

≥7 scale

Operating temperature

800 ℃ max

Crush strength

≥130Mpa



Spec.

Specific surface (m2/m3)

Bulk density     (kg/m3)

Void ratio

(%)

Obl. angle

Pressure drop
(mmHg/m)

Theo. Plate
(m-1)

Hydraulic diameter
(mm)

Liquid load
(m3/m2h)

Max. Factorm/s (Kg/m3)-1

125Y

125

320

90

45°

1.8

1.8

28

0.2-100

3

160Y

160

370

85

45°

2

2

15

0.2-100

2.8

250Y

250

420

80

45°

2

2.5

12

0.2-100

2.6

350Y

350

470

78

45°

2.5

2.8

10

0.2-100

2.5

400Y

400

500

75

45°

3

3

8

0.2-100

2

450Y

450

520

72

45°

4

4

7

0.2-100

1.8

550Y

550

620

74

45°

5.5

5-6

6

0.18-100

1.4

700Y

700

650

72

45°

6

7

5

0.15-100

1.3

100X

100

280

92

30°

1.5

1

30

0.2-100

3.5

125X

125

300

90

30°

1.8

1.5

28

0.2-100

3.2

160X

160

350

85

30°

2

1.8

15

0.2-100

3

250X

250

380

80

30°

2.5

2.3

12

0.2-100

2.8

350X

350

450

78

30°

3

2.5

10

0.2-100

2.6

400X

400

480

75

30°

4

2.8

8

0.2-100

2.2

450X

450

500

72

30°

4.5

3-4

7

0.2-100

2

470X

470

440

75

30°

5

5

7

0.2-100

1.8

550X

550

620

74

30°

5.5

5-6

6

0.18-100

1.4

700X

700

650

72

30°

6

7

5

0.15-100

1.3



Application

● Rectifying organic halide.

● Rectifying and absorbing some corrosive mixtures, which are definitely regulated in pressure drop and theoretic plate number.

● Applied in some towers that contain a large quantity of natural media used to absorb nitric acid and concentrated sulfuric acid, as well as for purifying the air in chemical plants.

● Operating in vacuum conditions at a bottom absolute pressure of 100pa.

● Used in heat ex changer and demisting, or as a catalyst carrier.

● Used in Chlorobenzene production.
