Ceramic Cross Partition Ring
Material: Alumina ceramic.
Apperance: Ceramic ring.
MOQ: 1 cubic meter.
Standard: HG/T 4369-2012.
Feature: High-performance packing, high mechanical strength, high surface area for better mass transfer efficiency.
Application: Widely used in chemical, petrochemical industry and environmental protection, to achieve gas-liquid mass transfer processes such as distillation, absorption, desorption, extraction, etc.
Description：
Ceramic cross partition, its shape is in the middle of ceramic raschig ring adds cross. It can improve the masss transfer efficiency of vapor and liquid. And also can be used in high or low temperature conditions.
Material: Alumina ceramic.
Apperance: Ceramic ring.
MOQ: 1 cubic meter.
Standard: HG/T 4369-2012.
Feature: High-performance packing, high mechanical strength, high surface area for better mass transfer efficiency.
Application: Widely used in chemical, petrochemical industry and environmental protection, to achieve gas-liquid mass transfer processes such as distillation, absorption, desorption, extraction, etc.
Description：
Ceramic cross partition, its shape is in the middle of ceramic raschig ring adds cross. It can improve the masss transfer efficiency of vapor and liquid. And also can be used in high or low temperature conditions.
Previous: Ceramic Raschig Ring
Next: Ceramic Intalox Saddle
|
Product Parameter
|
Chemical properties |
|||
|
Al2O3 |
17%~19% |
MgO |
<0.5% |
|
SiO2 |
>70% |
K2O+Na2O |
<3.5% |
|
Al2O3+SiO2 |
>92% |
Fe2O3 |
<1% |
|
CaO |
<1% |
Other |
<1% |
|
Physical properties |
|||
|
Water absorption |
<0.5% |
||
|
Specific gravity |
2.3~2.4 g/cm3 |
||
|
Acid resistance |
>99.6% |
||
|
Alkali resistance |
>85% |
||
|
Moh’s hardness |
>6.5 scale |
||
|
Operating temperature |
1200 ℃ max |
||
|
Specification |
||||||
|
Dia |
D*H*T |
Surface area |
Free volume |
Bulk number |
Bulk density |
Packing factor |
|
50 |
50*40*50*5 |
145 |
50 |
6400 |
600 |
565 |
|
80 |
80*64*80*8 |
120 |
56 |
1950 |
820 |
356 |
|
100 |
100*80*100*10 |
110 |
53 |
1000 |
850 |
252 |
|
120 |
120*96*120*12 |
75 |
55 |
370 |
860 |
146 |
|
150 |
150*120*150*15 |
60 |
58 |
295 |
980 |
101 |
|
|
| Description： The ceramic cross partition ring is developed based on the idea of increasing the specific surface of the filler to enhance the mass transfer efficiency. The cross baffle ring is an improvement on the raschig ring. The method of adding a baffle in a similar ring expands the ratio. Surface area, while increasing the compressive strength of the porcelain filler, it is usually used as a layered support for small fillers, with relatively low pressure drop, and less channeling and wall flow. Its structure is to add a cross partition in the raschig ring. Generally speaking, due to its large size, this kind of packing is only suitable for neat stacking, and is generally only used as a support distribution layer at the bottom of the tower for random packing. |
Product Parameter
|
Chemical properties |
|||
|
Al2O3 |
17%~19% |
MgO |
<0.5% |
|
SiO2 |
>70% |
K2O+Na2O |
<3.5% |
|
Al2O3+SiO2 |
>92% |
Fe2O3 |
<1% |
|
CaO |
<1% |
Other |
<1% |
|
Physical properties |
|||
|
Water absorption |
<0.5% |
||
|
Specific gravity |
2.3~2.4 g/cm3 |
||
|
Acid resistance |
>99.6% |
||
|
Alkali resistance |
>85% |
||
|
Moh’s hardness |
>6.5 scale |
||
|
Operating temperature |
1200 ℃ max |
||
|
Specification |
||||||
|
Dia |
D*H*T |
Surface area |
Free volume |
Bulk number |
Bulk density |
Packing factor |
|
50 |
50*40*50*5 |
145 |
50 |
6400 |
600 |
565 |
|
80 |
80*64*80*8 |
120 |
56 |
1950 |
820 |
356 |
|
100 |
100*80*100*10 |
110 |
53 |
1000 |
850 |
252 |
|
120 |
120*96*120*12 |
75 |
55 |
370 |
860 |
146 |
|
150 |
150*120*150*15 |
60 |
58 |
295 |
980 |
101 |
|
Application ● For absorption tower, can improve the absorption efficiency and purity. ● For desorption and distillation towers, can promte gas-liquid mass transfer. ● Suitable for the environmental equipment such as flue gas desulfurization towers. ● Mainly used for the drying tower and absorption tower of the acid industry. ● Widely used for the drying towers, absorption towers, cooling towers, washing towers and regeneration towers etc. |
