Ceramic Berl Saddle
Material: Alumina ceramic.
Apperance: Ceramic ring.
MOQ: 1 cubic meter.
Standard: HG/T 4369-2012.
Feature: Excellent resistance to acids, alkali, excellent heat resistance, high specific surface area and low cost.
Application: Used in scrubbers and regeneration tower in the metallurgy, industrial oxygen production industry, etc.
Description：
Ceramic berl saddle shape is similar to a saddle. Typically ranging in size from 10mm to 50mm. Its surface is open both inside and outside. Fluid distributed on both sides of the surface. It has high mechanical strength and energy saving low operation cost and easy to be load and unload advantages.
Material: Alumina ceramic.
Apperance: Ceramic ring.
MOQ: 1 cubic meter.
Standard: HG/T 4369-2012.
Feature: Excellent resistance to acids, alkali, excellent heat resistance, high specific surface area and low cost.
Application: Used in scrubbers and regeneration tower in the metallurgy, industrial oxygen production industry, etc.
Description：
Ceramic berl saddle shape is similar to a saddle. Typically ranging in size from 10mm to 50mm. Its surface is open both inside and outside. Fluid distributed on both sides of the surface. It has high mechanical strength and energy saving low operation cost and easy to be load and unload advantages.
Previous: Ceramic Cascade Mini Ring
Next: Carbon Raschig Ring
|
Product Parameter
|
Chemical properties |
|||
|
Al2O3 |
17%~19% |
MgO |
<0.5% |
|
SiO2 |
>70% |
K2O+Na2O |
<3.5% |
|
Al2O3+SiO2 |
>92% |
Fe2O3 |
<1% |
|
CaO |
<1% |
Other |
<1% |
|
Physical properties |
|||
|
Water absorption |
<0.5% |
||
|
Specific gravity |
2.3~2.4 g/cm3 |
||
|
Acid resistance |
>99.6% |
||
|
Alkali resistance |
>85% |
||
|
Moh’s hardness |
>6.5 scale |
||
|
Operating temperature |
1200 ℃ max |
||
|
Specification |
||||
|
Dia |
Surface area |
Free volume |
Bulk density |
Bulk number |
|
10 |
660 |
65 |
850 |
607142 |
|
15 |
225 |
58 |
725 |
83950 |
|
25 |
260 |
70 |
630 |
42000 |
|
38 |
110 |
72 |
617 |
12775 |
|
50 |
120 |
75 |
540 |
6667 |
|
|
| Description： Ceramic berl ring is also called ceramic berl saddle ring, ceramic bell ring. Ceramic berl saddle ring are interlocking in the tower and form arc air channel.Ceramic berl ring is benefit for evenly distribution of liquid and gas and it can reduce resistance. |
Product Parameter
|
Chemical properties |
|||
|
Al2O3 |
17%~19% |
MgO |
<0.5% |
|
SiO2 |
>70% |
K2O+Na2O |
<3.5% |
|
Al2O3+SiO2 |
>92% |
Fe2O3 |
<1% |
|
CaO |
<1% |
Other |
<1% |
|
Physical properties |
|||
|
Water absorption |
<0.5% |
||
|
Specific gravity |
2.3~2.4 g/cm3 |
||
|
Acid resistance |
>99.6% |
||
|
Alkali resistance |
>85% |
||
|
Moh’s hardness |
>6.5 scale |
||
|
Operating temperature |
1200 ℃ max |
||
|
Specification |
||||
|
Dia |
Surface area |
Free volume |
Bulk density |
Bulk number |
|
10 |
660 |
65 |
850 |
607142 |
|
15 |
225 |
58 |
725 |
83950 |
|
25 |
260 |
70 |
630 |
42000 |
|
38 |
110 |
72 |
617 |
12775 |
|
50 |
120 |
75 |
540 |
6667 |
|
Application ● Be interlocking in the tower and form arc air channel. ● Used in drying tower, absorption tower, cooling tower, washing tower, chemical industry, metallurgical industry, coal and natural gas industry, industrial oxygen production industry, etc. ● For acid towers, such as drying towers, absorption tower in sulphuric acid project or for dehydration towers. |
