Plastic Pall Ring
Material: PP, RPP, PE, PVC, CPVC, PVDF, PTFE etc.
Shape: Cylindrical.
MOQ: 1m3.
Standard: HG/T 3986-2016.
Feature: Large flux and small resistance, high separation efficiency, high mechanical strength and operational flexibility etc.
Application: Main used in chlorine drying tower, washing tower, petroleum and chemical, alkali chloride, gas and environmental protection industries.
Description：
Plastic pall ring has the advantages of large flux, low resistance, high separation efficiency and large operating flexibility. Under the same pressure drop, the processing capacity can be more than 50% larger than that of the raschig ring. At the same throughput, the pressure drop can be reduced by half, and the mass transfer efficiency can be increased by about 20%.
Material: PP, RPP, PE, PVC, CPVC, PVDF, PTFE etc.
Shape: Cylindrical.
MOQ: 1m3.
Standard: HG/T 3986-2016.
Feature: Large flux and small resistance, high separation efficiency, high mechanical strength and operational flexibility etc.
Application: Main used in chlorine drying tower, washing tower, petroleum and chemical, alkali chloride, gas and environmental protection industries.
Description：
Plastic pall ring has the advantages of large flux, low resistance, high separation efficiency and large operating flexibility. Under the same pressure drop, the processing capacity can be more than 50% larger than that of the raschig ring. At the same throughput, the pressure drop can be reduced by half, and the mass transfer efficiency can be increased by about 20%.
Previous: Plastic Raschig Ring
Next: Plastic Ralu Ring
|
Product Parameter
|
Specification of plastic pall ring |
||||||
|
Material: PP, RPP, PE, PVC, CPVC, PVDF, PTFE etc. |
||||||
|
Dia |
D*T |
Surface area |
Free volume |
Bulk number |
Bulk density |
F factor |
|
16 |
16*1.1 |
274 |
91 |
180000 |
90 |
249 |
|
25 |
25*1.2 |
175 |
90 |
53500 |
49 |
239 |
|
38 |
38*1.4 |
115 |
89 |
15800 |
42 |
220 |
|
50 |
50*1.5 |
112 |
90 |
6500 |
42 |
154 |
|
76 |
76*2.6 |
73 |
92 |
1930 |
34.7 |
94 |
|
|
| Description： Compared with the raschig ring, plastic pall ring has the characteristics of large production capacity, low resistance, and greater operating flexibility. Under normal circumstances, the pressure drop can be 50% larger than the raschig ring under the same pressure drop-and the pressure drop is higher than the raschig ring under the same treatment. 50%-70% smaller, the tower height can also be reduced. |
Product Parameter
|
Specification of plastic pall ring |
||||||
|
Material: PP, RPP, PE, PVC, CPVC, PVDF, PTFE etc. |
||||||
|
Dia |
D*T |
Surface area |
Free volume |
Bulk number |
Bulk density |
F factor |
|
16 |
16*1.1 |
274 |
91 |
180000 |
90 |
249 |
|
25 |
25*1.2 |
175 |
90 |
53500 |
49 |
239 |
|
38 |
38*1.4 |
115 |
89 |
15800 |
42 |
220 |
|
50 |
50*1.5 |
112 |
90 |
6500 |
42 |
154 |
|
76 |
76*2.6 |
73 |
92 |
1930 |
34.7 |
94 |
|
Application ● Suitable for distillation towers, adsorption towers and washing towers with low temperature 60-150 degrees. ● Used for desorption devices, atmospheric and vacuum distillation devices. v Used for desulfurization tower and regeneration tower of ammonia decarbonization, carbon dioxide washing tower and desulfurization system. |
