Carbon Molecular Sieve CMS280
Composition: Carbon.
CAS No.: 7440-44-0.
National standard: HG/T 4364-2020.
Application: High purity, high recovery rate for nitrogen production for pressure swing adsorption nitrogen generators.
Description：
Carbon molecular sieve CMS280 is a new type of nitrogen production molecular sieve developed on the basis of normal carbon molecular sieve. For the same nitrogen purity, the nitrogen production capacity of CMS-280 is higher than that of CMS-260 by 8-10%.
Composition: Carbon.
CAS No.: 7440-44-0.
National standard: HG/T 4364-2020.
Application: High purity, high recovery rate for nitrogen production for pressure swing adsorption nitrogen generators.
Description：
Carbon molecular sieve CMS280 is a new type of nitrogen production molecular sieve developed on the basis of normal carbon molecular sieve. For the same nitrogen purity, the nitrogen production capacity of CMS-280 is higher than that of CMS-260 by 8-10%.
Previous: Carbon Molecular Sieve
|
Product Parameter
| Properties | Data | ||||
| Diameter (MM) | 1.0~1.2 | ||||
| Crushing strength (N/PC) | 50~60 | ||||
| Apperance | Black Cylinder | ||||
| Composition | Carbon | ||||
| Bulk density (G/L) | 630-690 | ||||
| Adsorbent time (S) | 2*50 (Can be Adjustable) | ||||
| Type | Adsorbent pressure (MPa) | N2 purity (%) | N2 quantity (M3/MT.HT) | N2/Air (%) | |
| CMS-280 | 0.75-0.80 | 99 | 335 | 2.2 | |
| 99.5 | 280 | 2.5 | |||
| 99.9 | 190 | 2.3 | |||
| 99.99 | 135 | 4.5 | |||
| 99.999 | 90 | 6.4 | |||
Notice:
If possible, the test temperature is less or equivelent to 20 ℃, which can performance better nitrogen production.
It should be installed with quickly once open the drums, to avoid access more water, oil and other gas.
|
 |
| Description： Carbon molecular sieve, which is the appearance of cylindrical black solid, contains countless 4 angstrom fine pores. It is separated nitrogen from air. And concentrate nitrogen and high purity nitrogen recovery on every kind of PSA nitrogen generator. Under the different test temperature and pressure conditions, the production of nitrogen will be different. |
Product Parameter
| Properties | Data | ||||
| Diameter (MM) | 1.0~1.2 | ||||
| Crushing strength (N/PC) | 50~60 | ||||
| Apperance | Black Cylinder | ||||
| Composition | Carbon | ||||
| Bulk density (G/L) | 630-690 | ||||
| Adsorbent time (S) | 2*50 (Can be Adjustable) | ||||
| Type | Adsorbent pressure (MPa) | N2 purity (%) | N2 quantity (M3/MT.HT) | N2/Air (%) | |
| CMS-280 | 0.75-0.80 | 99 | 335 | 2.2 | |
| 99.5 | 280 | 2.5 | |||
| 99.9 | 190 | 2.3 | |||
| 99.99 | 135 | 4.5 | |||
| 99.999 | 90 | 6.4 | |||
Notice:
If possible, the test temperature is less or equivelent to 20 ℃, which can performance better nitrogen production.
It should be installed with quickly once open the drums, to avoid access more water, oil and other gas.
|
Application ● In the petroleum industry, nitrogen with a purity of 99.99-99.999% is required, mainly used for nitrogen purification in catalytic cracking towers, pipelines, etc. ● In the chemical industry, high-purity nitrogen is required, mainly used as protective gas for displacement, cleaning, and dry quenching. ● In the transfer of extremely flammable liquids under nitrogen pressure. ● In the electronics industry, in the manufacture of light bulbs. |
